7 DC04 SAN Director Installation
This chapter provides the following information:
• “Time and items required for installation” on page 125
• “Site preparation, unpacking the DC04 Director” on page 126
• “Items included with the DC Director” on page 128
• “Installing the DC04 Director in a rack” on page 128
• “Powering on the DC04 Director” on page 138
• “Port numbering” on page 139
• “Managing cables” on page 139
• “Using the optional HP StorageWorks DC SAN Backbone Director Inter-Chassis Link (ICL) cable kit” on page
140
Time and items required for installation
You can set up and install the DC04 SAN Director in the following ways:
• As a standalone unit on a flat surface.
• In a 19-in. Electronic Industries Association (EIA) cabinet using the port side exhaust kit (provided).
Table 25 describes the main installation and setup tasks and the estimated time required for each,
based on a fully populated DC04 SAN Director (192 FC ports). Configurations with fewer ports
require less time. These time estimates assume a prepared installation site and appropriate power
and network connectivity.
Table 25 Installation tasks, time and items required
Items requiredTime estim-
ate
Installation task
One 1/2-in. socket wrench (to remove pallet bolts)
One #2 Phillips screwdriver (for cable management
comb)
One pallet jack
Hydraulic lift or assisted lift, able to raise to a
minimum of 55 in. (140 cm), with a minimum capacity
of 113 kg (250 lb). The DC04 SAN Director weighs
68 kg (150 lb) with four FC8-48 port cards installed
(192 ports).
30 minutesPreparing the site and unpacking
DC04 SAN Director
Port side exhaust kit30 minutesInstalling the rack mount kit and
port side exhaust kit.
N/A15 minutesMounting and securing DC04
SAN Director in rack
HP StorageWorks DC and DC04 SAN Backbone Director Switches 125
