Optional items
Purchase the following items separately:
• Sixteen SFP transceivers
• Two SFP transceivers for the GbE ports
Installing and configuring the FR4-18i blade
To configure the FR4-18i, complete the following tasks:
1. “Installing the FR4-18i blade into the Director” on page 224
2. “Configuring FCIP and Fibre Channel Routing Services and enable the ports” on page 226
3. “Cabling the FR4-18i blade” on page 226
4. “Recommendations for cable management” on page 227
Installing the FR4-18i blade in the Director
To install the FR4-18i blade:
1. Select an empty slot in the Director.
2. Make sure the latches on the FR4-18i blade are unscrewed and open.
3. Slide the FR4-18i blade into the open slot.
4. Close and screw the latches and power on the blade using the ON/OFF slider switch (see Figure
74). The FR4-18i blade begins POST. After POST is complete, the firmware version on the blade
will autolevel with the firmware version on the active CP.
5. Verify that the blade power and blade status LEDs are green after the blade has completed
booting.
NOTE:
The FC ports are numbered from bottom to top, in eight-port groups, and are numbered
on the faceplate.
Intelligent blades224
