Simple Name Server; Registered State Change Notification (RSN); Advanced
Zoning; Web Tools; Fabric Watch; Extended Fabrics; ISL Trunking; End-to-End
Performance Monitoring, FICON CUP, ACL (Access Control Lists), Admin Domains,
Reliable Commit Service, NTP, Syslog, RASlog, auditing
Fabric services
Chassis-to-chassis linkage through connectors on the core switch blade (CR4S-8)Inter-chassis linking (ICL)
System size and weight
The weight of the DC SAN Director can vary considerably depending on the combination of blades
installed. Use Table 44 and Table 46 to determine the weight of the DC SAN Director with your
combination of Director blades.
Table 44 DC SAN Director system size and weight
Size and weightSystem
43.74 cm (17.22 in.)Width
61.24 cm (24.11 in./14U)Height
61.29 cm (24.09 in.)Depth
73.20 cm (28.82 in.)Depth (with door)
103.6 kg (228 lb.)DC SAN Director: 384-port configuration with eight FC8-
48 port blades
39.64 kg (87.2 lb.)Empty chassis:
• No blades
• No CP blade
• No core switch blade
• No power supplies
• No fan assemblies
Table 45 DC04 SAN Director system size and weight
Size and weightSystem
43.74 cm (17.22 in.)Width
61.24 cm (24.11 in./8U)
68.90 cm (27.12 in./9U) with Port Side Exhaust Kit
Height
61.29 cm (24.09 in.)Depth
73.20 cm (28.82 in.)Depth (with door)
68 kg (150 lb.)DC04 SAN Director: 192-port configuration with four
FC8-48 port blades
HP StorageWorks DC and DC04 SAN Backbone Director Switches 213
