Recommended actionStatusColorLED
pur-
pose
Change transceiver or reset switch
from workstation.
Transceiver or port is faulty.Fast-flashing amber (on
1/2 second, then off 1/2
second)
Reset port from workstation using the
portEnable or portCfgPersist-
entEnable command.
Port is bypassedAlternating green/amber
Monitoring Control Processor blade (CP8) status
To determine the status of a CP8 blade:
1. Check the LED indicators on the CP blade (see Figure 58). The LED patterns may temporarily
change during POST and other diagnostic tests. For information about how to interpret the LED
patterns, see Table 31.
2. Check port blade status by typing slotShow and haShow.
