14U Rack Mount Kit parts list
Table 8 and Figure 3 identify the hardware provided in the 4U rack mount kit that ships with your
DC SAN Director.
Table 8 Items supplied with the 14U rack mount kit (DC SAN Director)
QuantityDescriptionItem
For all types of installations
1
Left rack mount shelf bracket (rail brackets may differ from the il-
lustration)
A
1
Right rack mount shelf bracket (rail brackets may differ from the
illustration)
B
6
10-32 x 5/8 inch (1.58 cm) panhead Phillips screw, washer
(torque to 32 in.-lbs, 37 cm-kgs)
C
For cabinets that have rails with round holes
610-32 clip nutD
16
1/4-20 x 1/2 in. (1.27 cm) panhead Phillips screw, with lock
washer (torque to 80 in.-lbs, 92 cm-kgs)
E
For cabinets that have rails with square holes
610-32 retainer nutF
16
1/4-20 x 1/2 in. (1.27 cm) panhead Phillips screw, with glue
(torque to 80 in.-lbs, 92 cm-kgs)
G
160.375 in. (0.953 cm) alignment washerH
HP StorageWorks DC and DC04 SAN Backbone Director Switches 33
