Figure 11 Inter-chassis link (ICL) connections (configuration 1)
2. Core switch blades (CR8)1. Chassis 1
4. Port blades3. Core Processor blades (CP8)
6. ICL connector (ICL 0)5. ICL connector (ICL 1)
8. Chassis 27. ICL cables
HP StorageWorks DC and DC04 SAN Backbone Director Switches 45
