HP A7533A - Brocade 4Gb SAN Switch Base - Core Switch Blade (CR8)

ICL 0
LINK ATTN
ICL 0
LINK ATTN
ICL 1
LINK ATTN
26397a
1
2
3
4
5
Figure 22 Core switch blade (CR8)
2. Power LED1. Status LED
4. ATTN LED3. LINK LED
5. ICL connector
HP StorageWorks DC and DC04 SAN Backbone Director Switches 67
