HP A7533A - Brocade 4Gb SAN Switch Base - Control Processor Blade (CP8)

26401a
1 2
3
4
5
6
7
8
Figure 21 Control Processor blade (CP8)
2. Power LED1. Status LED
4. USB port3. USB LED
6. Ethernet port (MGMT)5. Console port (10101)
8. Active CP LED7. Ethernet port (SERVICE)
