A Technical specifications
This appendix provides information for both the DC SAN Director and the DC04 SAN Director.
Differences in specifications between the products is indicated. The following information is included:
General specifications” on page 209
System architecture” on page 210
System size and weight” on page 213
System blade and FRU weights” on page 214
Facility requirements” on page 214
Power specifications” on page 215
Power cords” on page 216
Environmental requirements” on page 219
Fibre Channel port specifications” on page 220
Data transmission ranges” on page 222
General specifications
The DC SAN Director and DC04 SAN Director are compliant with United States and International
safety and Electromagnetic Compatibility (EMC) Electromagnetic Compatibility standards. Table 41
lists the general specifications for the DC SAN Director and DC04 SAN Director.
Table 41 General specifications
DescriptionSpecification
F_Port, FL_Port, E_Port, EX_Port, VEX_Port, VE_Port, and M_PortConfigurable port types
Nonblocking shared memorySystem architecture
FreeScale 8548, 1.2 GHzSystem processor
FC-PH (Fibre Channel Physical and Signalling Interface standard)ANSI fibre channel protocol
Fibre Channel Class 2, Class 3, and Class FModes of operation
Complies with FC-SW 5.0Fabric initialization
Complies with FC-IP 2.3 of the FCA profileFC-IP (IP over fibre channel)
DC SAN Director: 6144 Gb/s, end-to-end
DC04 SAN Director: 3 Tbps per chassis
Aggregate I/O bandwidth
Less than 2 microseconds with no contention (destination port is
free)
Port to port latency
HP StorageWorks DC and DC04 SAN Backbone Director Switches 209
