Figure 39 Rack mount kit hardware
Torque requirements
Use the torque settings listed in Table 28 when tightening screws that secure the rack mount kit and
DC04 SAN Director to the equipment cabinet.
Table 28 Torque requirements
TorqueScrew size
10 cm-kg (8.75 in.-lbs)6-32 x .635 cm (0.25 in. ) Phillips screw
36.86 cm-kg (32 in.-lbs )10-32 x 1.60 cm 0(.63 in.) Phillips screw
DC04 SAN Director Installation130
