HP A7533A - Brocade 4Gb SAN Switch Base Hardware Reference Guide

Table 30 Director and application blade LED descriptions
Recommended actionStatusColorLED
pur-
pose
No action requiredBlade has been enabled.Steady greenPower
LED
Ensure blade is firmly seated.Blade has not been enabled.No light (LED is off)
Verify that the power LED is on.Blade is either healthy or does not
have power.
No light (LED is off)Status
LED
Ensure blade is firmly seated and
check status with slotShow com-
mand. If LED remains amber, contact
HP.
Blade is faulty.Steady amber
Pull blade out and reseat it. If LED
continues to flash, replace blade.
Blade is not seated correctly or is
faulty.
Slow-flashing amber (on
2 seconds, then off 2
seconds)
Check for out-of-bounds environment-
al condition and correct it.
Environmental range exceeded.Fast-flashing amber (on
1/2 second, then off 1/2
second)
Verify that the power LED is on,
check the transceiver and cable.
Port has no incoming power, or
there is no light or signal carrier
detected.
No light (LED is off)Port
Status
Allow 60 seconds for polling to
complete.
Polling is in progress.
Verify the status of the connected
device.
Connected device is configured
in an offline state.
No action requiredPort is online (connected to an
external device) but has no traffic.
Steady green
Verify that the correct device is at-
tached to the DC04 SAN Director.
Port is online but segmented, in-
dicating a loopback plug or cable
or an incompatible switch.
Slow-flashing green (on 1
second, then off 1
second)
No action requiredPort is in internal loopback (dia-
gnostic).
Fast-flashing green (on
1/4 second, then off
1/4 second
No action requiredPort is online, with traffic flowing
through port.
Flickering green
Reset port from workstation using the
portEnable or portCfgPersist-
entEnable command.
Port is receiving light or signal
carrier, but it is not online yet.
Steady amber
Reset port from workstation using the
portEnable or portCfgPersist-
entEnable command.
Port is disabled due to diagnostic
tests or portDisable or port-
CfgPersistentEnable com-
mand.
Slow-flashing amber (on
2 seconds, then off 2
seconds)
HP StorageWorks DC and DC04 SAN Backbone Director Switches 159
