• Flathead screwdriver
• Hydraulic or assisted lift with a minimum raise of 140 cm (55 in.) and a minimum capacity of
113 kg (250 lbs).
Rack mount kit contents
Table 27 and Figure 39 identify the hardware provided in the 4U rack mount kit that ships with the
DC04 SAN Director.
Table 27 Rack mount kit contents
QuantityDescriptionItem
1Top railA
1DuctB
1ShelfC
12
10-32 x 1.27 cm (0.5 in.) Phillips screw (blue Loctite
on threads)
D
12
10-32 x 1.60 cm (0.63 in.) Phillips screw with square
cone washer
E
8
10-32 clip nut for cabinets that have rails with round
holes
F
8
10-32 retainer nut for cabinets that have rails with
square holes
G
12
Alignment washer for cabinets that have rails with
square holes
H
26-32 x 0.635 cm (0.25 in.) Phillips screwI
HP StorageWorks DC and DC04 SAN Backbone Director Switches 129
