5. Attach the clip or retainer nuts to the vertical rails on the exhaust aisle side of the cabinet (see
Figure 5). These clip nuts are used for securing the port side of the chassis to the rack rails using
10-32 x 5/8-inch screws. Use three clips on each rail. Place the clips in optimum locations for
securing the chassis to the rails.
NOTE:
Do not align the clip or retainer nuts with the top or bottom holes of the mounting bracket
because the door will interfere with the screw heads.
• For rails with round holes:
Attach clip nuts (Item D) to each of the front rails.
• For rails with square holes:
Attach retainer nuts (Item F) to each of the front rails.
CAUTION:
Use the screws specified in the procedure. Using longer screws can damage the chassis.
Removing the chassis door
See “Removing the chassis door” on page 73 to remove the chassis door.
Installing the chassis in the cabinet
To install the DC SAN Director in the cabinet:
CAUTION:
A fully populated DC SAN Director (eight FC8-48 port cards, 384 ports) weighs approximately 104
kg (228 lbs) and requires a hydraulic or assisted lift to install it.
1. Use a lift to raise the chassis to the correct level.
2. Move the lift as close as possible to the rack, with the air-intake side of the chassis facing the
front of the rack (see Figure 6).
3. If applicable, lock the wheels of the lift.
4. Gently slide the chassis onto the shelf brackets, ensuring that it remains supported during the
transfer.
DC SAN Director Installation38
