Table 43 DC04 SAN Director system architecture
Up to 192 ports, universal (E_Port, F_Port, FL_port, Ex_port, and M_port)Fibre Channel Ports
Redundant (active/standby) control processor modulesControl Processor
Full fabric architecture: 239 switches maximumScalability
1.063 Gb/s line speed, full duplex
2.125 Gb/s line speed, full duplex
4.25 Gb/s line speed, full duplex
8.50 Gb/s line speed, full duplex
10.51875 Gb/s line speed, full duplex (with FC10-6 blade)
Autosensing of 1, 2, 4, and 8 Gb/s port speeds optionally programmable to fixed
port speed, speed matching between 1, 2, 4, and 8 Gb/s port speeds
Performance
Can use up to 8 ports in a trunk group to form a 64 Gb/s trunkISL Trunking
3 Tbps per chassisAggregate bandwidth
FC8-16 blade:
<2.1 µsec any port to any port at 8 Gb/s, cut-through routing.
For the FC8-32 blade:
<2.1 µsec any port to any port at 8 Gb/s, cut-through routing.
For the FC8-48 blade:
<2.1 µsec any port to any port at 8 Gb/s, cut-through routing.
For the FR4-18i blade:
<3.6 µsec any port to any port at 4 Gb/s, cut-through routing.
Switch latency
2112-byte payloadMaximum frame size
2048 per ASIC, dynamically allocatedFrame buffers
Class 2, Class 3, Class F (interswitch frames)Classes of service
The FC8-16 and FC8-32 supports these port types:
FL_Port, F_Port, E_Port, and M_Port
FC8-48 supports these port types:
E_Port, F_Port, and M_Port
FC10-6 supports this port type:
E_Port and M_Port
FR4-18i supports these port types:
FL_Port, F_Port, E_Ports, M_Port, VE_Port, EX_Port, and VEX_Port
NOTE: Self-discovery is based on switch type (U_Port) with an optional port type
control.
Port types
Fabric switches supporting unicast, multicast (255 groups), and broadcastData traffic types
Hot-pluggable, industry-standard small form factor pluggable (SFP) or extended
form factor pluggable (XFP, FC10-6 only), LC connector;
- short-wave laser (SWL), up to 500 m (1,640 ft.);
- long-wave laser (LWL), up to 10 km (6.2 mi);
- extended long-wave laser (ELWL), up to 80 km (49.6 mi); distance depends on
fiber optic cable and port speed
Media types
Technical specifications212
