Items requiredTime estim-
ate
Installation task
SFP and XFP (10-Gb/s) optical transceivers30 minutesInstalling SFP and XFP (10-Gb/s)
optical transceivers
Fiber optic cables, cable ties, and pillars60 minutesAttaching fiber optic cables, cable
ties, and cable guides
Serial cable (provided in the DC SAN Director access-
ory kit)
One workstation computer with a serial port or
terminal server port and a terminal emulator
application (such as HyperTerminal)
Three Ethernet addresses: one each for the DC SAN
Director, CP blade, and Core switch blade
10 minutesEstablishing serial connection,
logging on to DC SAN Director,
and configuring IP addresses
Ethernet cabling (optional) for Telnet access. All other
configuration parameters are optional. Refer to the
HP StorageWorks Fabric OS 6.2.x administrator
guide for Port Identifier (PID).
20 minutesInstalling Ethernet cable(s) and
configuring the DC SAN Director
name, policies, domain ID, PIDs,
or additional system parameters
Site preparation, unpacking the DC SAN Director
IMPORTANT:
See “Regulatory compliance and safety notices” on page 229 for important safety guidelines before
setting up the DC SAN Director.
The following steps are required to ensure correct installation and operation:
1. Provide a space that is 14 rack units (14U) high, 61.29 cm (24.09 in.) deep, and 43.74 cm
(17.22 in.). 1U is equal to 4.45 cm (1.75 in.)
2. Plan to install the DC SAN Director with the non-port side facing the aisle. The DC SAN Director
can be installed facing either direction, if serviceability and cooling requirements are met.
3. Plan for cable management before installing the chassis (see “Managing cables” on page 43).
Cables can be managed in a variety of ways, such as by routing cables below the chassis, to
either side of the chassis, through cable channels on the sides of the cabinet, or by using patch
panels.
DC SAN Director Installation30
