2 DC SAN Director Installation
This chapter provides the following information:
• “Time and items required for installation” on page 29
• “Site preparation, unpacking the DC Director” on page 30
• “Items included with the DC Director” on page 32
• “Installing the DC Director in the 14U Rack Mount Kit” on page 32
• “Powering on the DC Director” on page 42
• “Port numbering” on page 42
• “Managing cables” on page 43
• “Using the optional HP StorageWorks DC SAN Backbone Director Inter-Chassis Link (ICL) cable kit” on page
43
Time and items required for installation
You can set up and install the DC SAN Director in the following ways:
• As a standalone unit on a flat surface.
• In a 19-in. EIA cabinet, using the 14U Rack Mount Kit (ships with the DC SAN Director).
Table 6 describes the main installation and setup tasks and the estimated installation time, based
on a fully populated DC SAN Director (384 FC ports). Configurations with fewer ports require
less time. These time estimates assume a prepared installation site and appropriate power and
network connectivity.
Table 6 Installation tasks, time and items required
Items requiredTime estim-
ate
Installation task
One 1/2-in. socket wrench (to remove pallet bolts)
One #2 Phillips screwdriver (for cable management
comb)
One pallet jack
One hydraulic lift or assisted lift, able to raise to a
minimum of 140 cm (55 in.), with a minimum capacity
of 113 kg (250 lb). The DC SAN Director weighs
104 kg (228 lb) with eight FC8-48 port cards installed
(384 ports).
30 minutesSite preparation and unpacking
DC SAN Director
See “Installing the DC Director in the 14U Rack Mount
Kit” on page 32.
30 minutesInstalling rack mount kit
30 minutesMounting and securing DC SAN
Director in rack
Power cables and serial cable (provided in the DC
SAN Director accessory kit)
20 minutesInstalling power cables and
powering on the DC SAN Director
HP StorageWorks DC and DC04 SAN Backbone Director Switches 29
