4. Ensure that dedicated electrical branch circuits with the following characteristics are available:
• 200—240 VAC, 50–60 Hz (two branch circuits)
• Protected by a circuit breaker in accordance with local electrical codes
• Supply circuit, line fusing, and wire size adequate to the electrical rating on the chassis
nameplate
• Location close to the chassis and easily accessible
• Grounded outlets installed by a licensed electrician, compatible with the power cords
TIP:
To maximize fault tolerance, connect each power cord to a separate power source.
5. Ensure that the air intake and exhaust vents have a minimum of 2 in. of airspace.
6. Ensure that the air temperature on the air intake side is less than 40˚ Celsius (104˚ Fahrenheit)
during operation.
CAUTION:
Use safe lifting practices when moving the product. A fully populated DC04 SAN Director
(four FC8–48 port cards, 192 ports) weighs approximately 68 kg (150 lbs) and requires a
hydraulic or assisted lift to install.
NOTE:
The DC04 SAN Director packaging does not include a wood pallet and pallet brackets. The
chassis sits on top of a plastic shipping tray.
7. Remove the upper portion of the shipping crate.
a. Cut the bands around the packaging.
b. Lift the carton off the chassis, leaveing the foam on top of the chassis to hold the kits in place
during transfer to the installation area. Save the shipping carton for future use.
c. Leave the chassis on top of the plastic shipping tray if the chassis must be transported to the
installation location.
8. Verify the contents of the carton against the list in Items included with the DC Director, page 128.
9. Use a pallet jack or other assisted lift to transport the new chassis to the installation area. Doorways
must be wider than 91 cm (36 in).
10. Remove the port side exhaust kit, shipping bracket kit, accessory kit, packing foam, and antistatic
plastic from the chassis and set aside.
HP StorageWorks DC and DC04 SAN Backbone Director Switches 127
