• Optionally, if you choose database authentication mode, Oracle database user
account. The user account is used by BRBACKUP and BRARCHIVE during backup.
• Directory in which the SAP backup utilities are stored
Data Protector then creates the configuration file for the SAP R/3 database on the
Cell Manager and verifies the connection to the database. On UNIX, Data Protector
also creates a soft link for the backint program from the directory that stores the
SAP backup utilities to /opt/omni/lbin.
On Windows, Data Protector copies the backint and programs (the latter only if
splitint is supported by BR*Tools) from Data_Protector_home\bin to the
directory that stores the SAP backup tools and renames ob2smbsplit.exe to
splitint.exe.
To configure an SAP R/3 database, use the Data Protector GUI or CLI.
Before you begin
• Ensure that the SAP R/3 database is open.
Using the Data Protector GUI
1. In the Context List, click Backup.
2. In the Scoping Pane, expand Backup Specifications, right-click SAP R/3, and
click Add Backup.
3. In the Create New Backup dialog box, select the template.
In the Backup type drop-down list, select the Split mirror backup.
Click OK.
4. In Application system, select the SAP R/3 client to be backed up. In cluster
environments, select the virtual server.
In Backup system, select the backup system.
Specify other disk array specific backup options (see Figure 48 on page 196 for
EMC, Figure 49 on page 197 for XP, Figure 50 on page 198 for VA, or Figure
51 on page 199 for EVA). For details on the options, press F1.
NOTE:
XP, VA, and EVA only:
To enable instant recovery, select
Track the replica for instant recovery.
Zero downtime backup integration guide 183
