Warning
Correct sample vial dimensions are essential for proper operation. Vials that do not comply
with these guidelines should cause autosampler errors. Service calls and repairs found to
be due to vials and microvials that do not comply with these guidelines are not covered
under warranty or the service contract.
12.2.1.1 Specifications for 20ml vials
x
Figure 131: 20ml sample vial dimensions
10mm
min
79mm
max
77mm min
67mm
ma
2mm
min
22.4mm
to
23.0mm
