HT2000H_en_n.doc Page 17 of 167
Width (open oven cover) 350mm
Depth (closed tray) 320mm
Depth (open tray) 520mm
HT2100H
Height 640mm
Width 280mm
Depth 320mm
WEIGHT
HT2000H/HT2000HT 10kg
HT2100H 8kg
ELECTRICAL SPECIFICATIONS
Power supply:
Voltage 100-240 ±10%Vac
Frequency 50-60Hz
Max Current 1.6 A (HT2000H/HT2000HT); 1.4-0.7 (HT2100H)
Autosampler HT2000H/HT2000HT:
Voltage 24Vdc
Power 120W
Autosampler HT2100H:
Voltage 24Vdc
Power 60W
INTERFACE SPECIFICATIONS
To GC TTL
To PC Ethernet 10/100
Optional: RS232C (available on a limited number
of models)
Ethernet cable should be Category 5 (or higher)
RS232 cable: max distance PC – autosampler: 1.80m (opt. 3.50m)
ADDITIONAL REQUIREMENTS (for HT2100H only)
HT2100H requires a PC for set up, service, method and sequence editing
