HT2000H_en_n.doc Page 96 of 167
Maintenance
Warning
Normal: the Maintenance Warning messages will be displayed at the begin-
ning of each run, if the set limit is reached (see 4.2.4.5).
Only at Start up: the Maintenance Warning messages will be displayed only
at Start up, if the set limit is reached (see 4.2.4.5).
• User Interface. It set the modality of the Home screen.
User Interface
Standard: The Home screen will be in the Standard modality (to see the
functions accessible from this screen see paragraph 7.1.1 ).
Quick Start: The Home screen will be in the Quick modality.
is a simplified modality in which you can start working by simply tapping
“Start” (to see the functions accessible from this screen see paragraph
7.1.2).
Select “Exit” to exit from this screen and return to the “Setup Configuration”” screen (see
paragraph 4.2.4 “Setup: Configuration“).
4.2.4.4 Setup configuration: Input Output
Access sequence: RUN>SETTINGS>SETUP>CONFIGURATION>INPUT OUTPUT
From here, it is possible to change the input / output parameters to/from the analyzer:
• Ready on: sets the “ON” state of the “Ready” signal. This signal is used to start the
sampler and must match the signal given by the analyzer.
Ready on
Low: the autosampler starts the injection when the analyzer provides a low logi-
cal level of voltage for the “Ready” signal;
High: the autosampler starts the injection when the analyzer provides a high log-
ical level of voltage (+5V) for the “Ready” signal
• Start on: to set the “ON” state of the “Start” signal from the autosampler to the analyzer
during the injection. This parameter has to be set according to the analyzer.
Open: during the injection (for about 1 second) the pins 3 (SAMPINS-N
(SAMPINS COM) are open, while before and after the injection they are closed
(see paragraph 13.1 GC connector”).
