Figure 4-4 Removing a rectier
Step 4 Push the locking latch on the new rectier towards the left, and pull out the
handle.
Step 5 Place the new rectier at the entry to the correct slot.
Step 6 Gently slide the converter into the slot along guide rails until it is engaged. Close
the handle, and push the locking latch towards the right to lock the handle.
Figure 4-5 Installing a
rectier
Step 7 Take o protective gloves.
----End
Follow-up Procedure
Pack the removed component, and return it to Huawei local warehouse.
4.3.4 Replacing an S4875G1
Prerequisites
● You have obtained a pair of protective gloves, the cabinet door key, and a
toolkit.
● The new SSU is intact.
CA UTION
Protect yourself from being burnt when moving an operating SSU because it has a
high temperature.
iSitePower Integrated Smart Site (ICC1000-A1-E1)
User Manual 4 Maintenance
Issue 04 (2022-10-15) Copyright © Huawei Technologies Co., Ltd. 121
