C Power Distribution of Circuit Breakers
on the Power Subrack
The description in the following table is for reference only. The actual cable
connection prevails.
Table C-1 Circuit breaker power distribution
Item
LLVD BLVD
Silk screen F1, F2，F3，F4 F5 F6 F7 F8
Capacity 125 A 125 A 125 A 125 A 63 A
ICC1000-A1-E1 Reserved (inverter) Inverter Inverter DCDB48-200-16B Reserved
Table C-2 DCDB48-200-16B power distribution description
Silk Screen
Capacity Load
F1 32 A Reserved
F2 32 A Air conditioner 1
F3 32 A Air conditioner 2
F4 32 A Air conditioner 3
F5 32 A Air conditioner 4
F6 16 A Heater 1
F7 16 A Heater 2
F8 10 A Smart ETH gateway
F9 10 A Light 1
F10 10 A Light 2
iSitePower Integrated Smart Site (ICC1000-A1-E1)
User Manual
C Power Distribution of Circuit Breakers on the
Power Subrack
Issue 04 (2022-10-15) Copyright © Huawei Technologies Co., Ltd. 164
