3.1.4.2 EPM240-M2C
A DG converts chemical energy into electricity. In a DG, the engine converts
thermal energy into mechanical energy, and then the generator converts
mechanical energy into electricity.
Figure 3-11 EPM240-M2C exterior
(1) Waterproof cap (2) Fuel tank (3) Soundproof canopy
(4) EMERGENCY STOP button (5) Fuel ller port (behind the
door)
Table 3-7 DG technical specications
Item
EPM240-M2C
Dimensions (H x W x D) 1925 mm x 950 mm x 2200 mm
Weight (excluding fuel) About 1000 kg
Engine model Weichai WP2.3D33E200
Generator model Xingnuo XN184G
Rated output power 24 kW/30 kVA
Output voltage 230 V AC/400 V AC, three-phase four-wire, 50
Hz
Fuel tank capacity 1000 L
Maintenance interval 1250 operating hours
Noise ≤ 75 dB (1 m, 75% of rated load)
