3.2.24 (Optional) Leakage Protection Box ACDB220-40-1B
NO TICE
The RCD supports automatic switch reclosing. If you need to manually power o
an RCD, you need to rst switch to the manual mode. Otherwise, delayed
automatic switch-on will occur in automatic mode.
Panel
Figure 3-56 Panel
(1) Automatic/Manual switch
(2) Automatic reclosing RCD
Technical specications
Table 3-57 Technical specications
Item
Specications
Dimensions (H x W
x D)
153 mm x 167 mm x 65 mm (excluding the protruding
part of the circuit breaker)
Weight 2 kg
Operating
temperature
-20°C to +55°C
Transportation
temperature
–40°C to +70°C
Storage
temperature
–40°C to +70°C
