3.2.22 (Optional) Power Distribution Unit PDU2000-32-1PH-9
Appearance and Panel
Figure 3-52 Appearance of the PDU2000-32-1PH-9
Figure 3-53 PDU panel
(1) Input wiring terminal
(2) Switch of the power
distribution bar
(3) AC output socket
Technical Specications
Table 3-55 PDU2000-32-1PH-9 technical specications
Item
Specications
Dimensions (H x W
x D)
44.4 mm x 55 mm x 921 mm
Weight About 10 kg
Operating voltage 220–240 V AC
Output voltage 220–240 V AC
Output current Nine 10 A outputs and three 16 A outputs
3.2.23 (Optional) AC Distribution Unit ACDB220-63-12B
The ACDB220-63-12B distributes AC power for the power system and provides
twelve 16 A AC outputs. It can be installed on a 19-inch rack and has good surge
protection capability.
