USB Port
You can quickly deploy a site, import and export conguration les, export run
logs, and upgrade software by inserting the USB ash drive that is specially used
for site deployment into the USB port.
After installing a dedicated WiFi module on the USB port, you can access the
WebUI locally.
NO TICE
Using a WiFi module not provided by the Company may cause function
abnormalities or data loss. The Company will not be liable for any loss caused
thereby.
Communications Ports
Table 3-14 Communications port description
Communications
Port
Communications
Parameter
Communications
Protocol
Function
FE 10M/100M
autonegotiation
SNMP protocol Connects to a
third-party NMS.
BIN protocol Connects to a
Huawei NMS.
HTTPS protocol Connects to a PC
and manages the
SMU over the
WebUI.
TCP-Modbus
protocol
Adapts to Huawei
TCP-Modbus and
connects to a
third-party NMS.
RS485/RS232 Baud rate: 1200
bit/s, 2400 bit/s,
4800 bit/s, 9600
bit/s, 14400 bit/s,
19200 bit/s,
115200 bit/s
Master/Slave
protocol
Connects to a
Huawei NMS.
YDN protocol Connects to a
third-party NMS.
CAN Baud rate: 125
kbit/s
CAN protocol Connects to
Huawei
southbound
devices.
NOTE
All the preceding ports are protected by security mechanisms.
