Huawei iSitePower - Optional) PVDU-150 A1

Table 3-41 PVDU-80A1 technical specications
Item Specications
Dimensions (H x W x
D)
43.6 mm x 482.6 mm x 122 mm (including mounting
ears)
Weight 2.6 kg
Input 70–150 V DC; max. 4x60 A
Output 70–150 V DC; max. 4x60 A
Installation mode Installed in a 19-inch rack
Cabling mode Routed in from the left and right
Maintenance mode Maintained from the front
Operating temperature –20°C to +65°C
Storage temperature –40°C to +70°C
Operating humidity 5%–95% RH (non-condensing)
Altitude 0–4000 m (When the altitude ranges from 2000 m to
4000 m, the operating temperature decreases by 1°C
for each additional 200 m)
Protection level IP20
3.2.15 (Optional) PVDU-150A1
Figure 3-37 PVDU-150A1 exterior
iSitePower Integrated Smart Site (ICC1000-A1-E1)
User Manual 3 Components
Issue 04 (2022-10-15) Copyright © Huawei Technologies Co., Ltd. 62
