For details about a DG, see the DG user manual.
3.1.4.3 EPM100-M2E
A DG converts chemical energy into electricity. In a DG, the engine converts
thermal energy into mechanical energy, and then the generator converts
mechanical energy into electricity.
Figure 3-12 EPM100-M2E exterior
(1) Waterproof cap
(2) Soundproof canopy (3) EMERGENCY STOP button
(4) Fuel ller port (behind the
door)
(5) Fuel tank
Table 3-8 DG technical specications
Item
EPM100-M2E
Dimensions (H x W x D) 1825 mm x 950 mm x 1800 mm
Weight (excluding fuel) About 846 kg
Engine model Yanmar 3TNV88-GGE
Generator model Xingnuo XN164D
Rated output power 10 kW/12 kVA
Output voltage 230 V AC/400 V AC, three-phase four-wire, 50
Hz
iSitePower Integrated Smart Site (ICC1000-A1-E1)
User Manual 3 Components
Issue 04 (2022-10-15) Copyright © Huawei Technologies Co., Ltd. 34
