Item Specications
Surge protection
level
Nominal lightning strike discharge current: 30 kA (8/20
μs); maximum lightning strike discharge current: 60 kA
(8/20 μs)
IP rating IP20
3.2.21 (Optional) Power Distribution Unit PDU2000-16-1PH-7
Appearance and Panel
Figure 3-50 Appearance of the PDU2000-16-1PH-7
Figure 3-51 PDU panel
(1) Input terminal (behind the cover)
(2) Output sockets
Technical Specications
Table 3-54 PDU2000-16-1PH-7 technical specications
Item
Specications
Dimensions (H x W
x D)
44.5 mm x 44.5 mm x 484 mm
Weight About 2.4 kg
Operating voltage 220–240 V AC
Output voltage 220–240 V AC
Output current 10 A for each route; maximum system output: 32 A
