E Associations Between Alarms and Dry
Contacts on the UIM
Table E-1 Associations between dry contacts and alarms
Dry Contact Type Silkscreen Associated Alarm
Dry contact inputs DIN1 AC SPD fault alarm
DIN2 Vibration sensor alarm
DIN3 User-dened
DIN4 Heater fault alarm
Dry contact outputs
The default setting
(closed: alarm;
open: normal) can
be modied.
ALM1 Dened as DIN1. An alarm is generated when the
dry contact is open.
ALM2 Dened as DIN2. An alarm is generated when the
dry contact is open.
ALM3 Dened as DIN3. An alarm is generated when the
dry contact is closed.
ALM4 User-dened
ALM5 Heater 1 start/stop control
ALM6 Heater 2 start/stop control
ALM7 User-dened
ALM8 User-dened
