3.2.16 (Optional) Air Purier
Figure 3-39 Appearance
(1) Wiring port
NO TE
In the system, the air
purier fan is fan 2.
3.2.17 (Optional) Fan Assembly (FAN-S04)
Figure 3-40 Appearance
(1) Wiring port
NO TE
The two fans in the fan assembly are fan 1 and fan 3, and they are ow fans.
3.2.18 (Optional) Inverter
The ETP23006-C1A1 converts –48 V DC power into 220 V AC/230 V AC power and
supplies high-performance power to AC devices.
3.2.18.1 Inverter ETP23006-C1A1
Appearance
Figure 3-41 ETP23006-C1A1 appearance
iSitePower Integrated Smart Site (ICC1000-A1-E1)
