Huawei iSitePower - Page 40

Figure 3-10 EPM180-M2B exterior
(1) Smoke exhaust vent (2) Fuel tank (3) Soundproof canopy
(4) EMERGENCY STOP button (5) Fuel ller port (behind the
door)
Table 3-6 DG technical specications
Item
EPM180-M2B
Dimensions (H x W x D) 1825 mm x 950 mm x 1800 mm
Weight (excluding fuel) About 950 kg
Engine model Weichai WP2.3D25E200
Generator model Xingnuo XN184E
Rated output power 18 kW/22.5 kVA
Output voltage 230 V AC/400 V AC, three-phase four-wire, 50
Hz
Fuel tank capacity 800 L
Maintenance interval 1250 operating hours
Noise ≤ 75 dB (1 m, 75% of rated load)
NO TE
For details about a DG, see the DG user manual.
iSitePower Integrated Smart Site (ICC1000-A1-E1)
User Manual 3 Components
Issue 04 (2022-10-15) Copyright © Huawei Technologies Co., Ltd. 32
