Figure 3-80 Port description
(1) Network port (2) Power input port
(3) RS485 port (4) Alarm port
(5) Audio port
Table 3-69 Technical specications
Item
Specications
Weight 0.7 kg
Dimensions (H x W x D) 90 mm x 109 mm x 210 mm
Camera Inside the Cabinet
Figure 3-81 Appearance of the camera
iSitePower Integrated Smart Site (ICC1000-A1-E1)
User Manual 3 Components
Issue 04 (2022-10-15) Copyright © Huawei Technologies Co., Ltd. 91
