Hypertherm Powermax45 XP User Manual

Cut Charts and Marking Charts
9
Powermax45 XP Operator Manual 809240 123
Each cut chart lists hot and cold gas flow rates.
 Hot flow rate – Plasma is on, the system is operating at running current, and the system is in a
steady state at the default system pressure (cutflow, or automatic mode).
 Cold flow rate – Plasma is off and the system is in a steady state with gas flowing through the
torch at the default system pressure (postflow).

Hypertherm collected the cut chart data under laboratory test conditions using
new consumables.
ARC WELDING SUPPLIES - 07 847 7870

Hypertherm Powermax45 XP Specifications

General

Output Current	10-45 A
Gas Supply	Clean, dry, oil-free air or nitrogen
Torch Style	Handheld or mechanized
Input Voltage	50/60 Hz
Cutting Thickness	12 mm (1/2")
Cutting Capacity	16 mm (5/8 in)
Recommended Gas Inlet Flow Rate/Pressure	6.2 bar
