Hypertherm Powermax45 XP User Manual

Installation and Setup
1
30 809240 Operator Manual Powermax45 XP
CCC 380 V (3-phase)
CE 400 V (3-phase)
CSA 480 V (3-phase)
Input voltage 380 V
Input current at rated output (45 A x 145 V = 6.5 kW) 12 A
Input current at arc stretch 20 – 15 A
Recommended fuse/breaker size 20 A
Voltage tolerance +20% / -15%
Input voltage 400 V
Input current at rated output (45 A x 145 V = 6.5 kW) 11 A
Input current at arc stretch 20 – 15 A
Recommended fuse/breaker size 20 A
Voltage tolerance +20% / -15%
Input voltage 480 V
Input current at rated output (45 A x 145 V = 6.5 kW) 9.4 A
Input current at arc stretch 17 – 12 A
Recommended fuse/breaker size 20 A
Voltage tolerance +20% / -15%
ARC WELDING SUPPLIES - 07 847 7870

Hypertherm Powermax45 XP Specifications

General

Output Current	10-45 A
Gas Supply	Clean, dry, oil-free air or nitrogen
Torch Style	Handheld or mechanized
Input Voltage	50/60 Hz
Cutting Thickness	12 mm (1/2")
Cutting Capacity	16 mm (5/8 in)
Recommended Gas Inlet Flow Rate/Pressure	6.2 bar
