Hypertherm Powermax45 XP User Manual

Powermax45 XP Operator Manual 809240 19
Installation and Setup
The Powermax45 XP is a portable 45 A plasma cutting system that you can use for many handheld
and mechanized cutting and gouging applications. The system’s automatic gas and
automatic voltage features make it easy to set up and use even if you have limited plasma cutting
experience.
With the Powermax45 XP you can:
 Use air or nitrogen to cut electrically
conductive metals such as mild steel,
stainless steel, and aluminum
 Cut thicknesses up to 16 mm (5/8 inch)
 Pierce thicknesses up to 12 mm (1/2 inch)
 Sever thicknesses up to 29 mm (1-1/8 inch)
 Use 2 different gouging processes for a wide
range of gouging applications: Maximum
Control gouging (26 A – 45 A) and Precision
gouging (10 A – 25 A)
 Mark metal surfaces using air or argon
 Use F5 to cut stainless steel
 Disable the Duramax Lock hand and machine
torches without turning OFF the power supply
using the torch-disable switch
 Quickly switch between torches using the
FastConnect™ system (quick-disconnect)
ARC WELDING SUPPLIES - 07 847 7870

Hypertherm Powermax45 XP Specifications

General

Output Current	10-45 A
Gas Supply	Clean, dry, oil-free air or nitrogen
Torch Style	Handheld or mechanized
Input Voltage	50/60 Hz
Cutting Thickness	12 mm (1/2")
Cutting Capacity	16 mm (5/8 in)
Recommended Gas Inlet Flow Rate/Pressure	6.2 bar
