Hypertherm Powermax45 XP User Manual

Installation and Setup
1
Powermax45 XP Operator Manual 809240 29
CSA/CE/CCC 200 V – 240 V (1-phase)
CSA 208 V (1-phase)
CCC 220 V (1-phase)
CE 230 V (1-phase)
Input voltage 200 V – 240 V
Input current at rated output (45 A x 145 V = 6.5 kW) 39 A – 32 A
Input current at arc stretch 44 A – 36 A
Recommended fuse/breaker size 50 A
Voltage tolerance +10% / -10%
Input voltage 208 V
Input current at rated output (45 A x 145 V = 6.5 kW) 37 A
Input current at arc stretch 43 A
Recommended fuse/breaker size 50 A
Voltage tolerance +10% / -10%
Input voltage 220 V
Input current at rated output (45 A x 145 V = 6.5 kW) 33 A
Input current at arc stretch 39 A
Recommended fuse/breaker size 50 A
Voltage tolerance +10% / -10%
Input voltage 230 V
Input current at rated output (45 A x 145 V = 6.5 kW) 33 A
Input current at arc stretch 37 A
Recommended fuse/breaker size 48 A
Voltage tolerance +10% / -10%
ARC WELDING SUPPLIES - 07 847 7870

Hypertherm Powermax45 XP Specifications

General

Output Current	10-45 A
Gas Supply	Clean, dry, oil-free air or nitrogen
Torch Style	Handheld or mechanized
Input Voltage	50/60 Hz
Cutting Thickness	12 mm (1/2")
Cutting Capacity	16 mm (5/8 in)
Recommended Gas Inlet Flow Rate/Pressure	6.2 bar
