Hypertherm Powermax45 XP User Manual

Installation and Setup
1
Powermax45 XP Operator Manual 809240 25
 Place the power supply on a
stable, level surface before using.
It can tip over if set at an angle
greater than 10°.
 Do not place the power supply
on its side. Doing so can block
the louvers on the side of the
cover and prevent proper air
circulation needed to cool
internal components.
>10°
ARC WELDING SUPPLIES - 07 847 7870

Hypertherm Powermax45 XP Specifications

General

Output Current	10-45 A
Gas Supply	Clean, dry, oil-free air or nitrogen
Torch Style	Handheld or mechanized
Input Voltage	50/60 Hz
Cutting Thickness	12 mm (1/2")
Cutting Capacity	16 mm (5/8 in)
Recommended Gas Inlet Flow Rate/Pressure	6.2 bar
