Up to four Power Distribution Units may be installed in the #0551. The PDUs may
be ordered as part of the initial order or added at a later time. Each PDU has six
power sockets that provide power for devices that support the #1422 PDU Line
Cord. A country (region)-specific line cord must be ordered for each PDU to
connect to external power.
The supported PDUs are:
#5160 Power Distribution Unit - 1 Phase NEMA
#5161 Power Distribution Unit - 1 Phase IEC
#5162 Power Distribution Unit - 2 of 3 Phase
#5163 Power Distribution Unit - 3 Phase
#7188 Power Distribution Unit - 1 or 3 Phase
The supported specify codes are:
#0121 Lower Unit in Rack Specify (270) (
withdrawn from marketing 21
November 2003)
#0122 Upper Unit in Rack Specify (270) (
withdrawn from marketing 21
November 2003)
#0133 Plant Install in Rack
– #0133 Plant Install in Rack feature is used to mount a Model 270, 800 or
810 system unit (sidecar feature must be present) in a #0551 rack either in
the plant or in the field.
– #0133 Plant Install in Rack is IBM installed in the plant or customer
installed in the field.
– #0133 can be ordered on initial orders, MES orders, or model upgrades
into the Model 810.
– If the system order received at the plant contains a system unit, sidecar
feature (#7104 or #7116), #0551 rack, and the #0133, the system is
mounted in the #0551 at the plant. If any of these four components are
missing from the order, the system is
not mounted in the #0551 at the
plant.
– It the system is not installed in a #0551 in the plant, the #0133 feature
provides the hardware components: a set of “slides”, cable management
arm, a heavy duty tray, a 270/800/810 adapter plate, and a pair of
270/800/810 lift covers. The #0133 is customer installed in the field.
– A line cord is required for both the system unit and the system unit
expansion.
