4 Using the Data
14-38 WindO/I-NV4 User’s Manual
Copying Data when UBIN32(D), BIN32(L), BCD8(EB) or Float32(F) is Selected as the Data Type
When one of UBIN32(D), BIN32(L), BCD8(EB) or Float32(F) is selected for Data Type on the Data tab in the
Individual Settings dialog box, two destination device addresses are required for a single item of data.
■ Example
Copying the newest data in the Data Log with the Data Type selected as UBIN32(D) to the destination device
address LDR10.
Item Setting
Destination Device Address LDR10
Starting Point Newest Data
Number of Data 2
Stored Order of Data From Newest to Oldest
Data log data
Sampling Time Value Destination Device Address Value
12/18/2011 17:44:10
87654321
(Hex)
Configured
device address
→
LDR10 3344
← Copy from
newest data
LDR11
LDR12
1122
::
7788
12/19/2011 19:24:43
12345678
(Hex)
LDR13
5566
12/19/2011 20:01:54
55667788
(Hex)
Newest data
read starting point
→
12/19/2011 21:39:21
11223344
(Hex)
Amount of data: 2
The data copy order for the device address selected with UBIN32(D), BIN32(L), BCD8(EB) or
Float32(F) as Data Type is configured with Storage Method of 32-bit Numerical Data on the
System tab in the Project Settings dialog box. For details, refer to Chapter 4 “3.1 System Tab” on page
4-25.
