6 Message Switching Display
10-118 WindO/I-NV4 User’s Manual
6.2 Message Switching Display Configuration Procedure
This section describes the configuration procedure for Message Switching Displays.
1 On the Home tab, in the Parts group, click Data Displays, and then click Message Switching Display.
2 Click a point on the edit screen where you wish to place the Message Switching Display.
3 Double-click the dropped Message Switching Display and a Properties dialog box will be displayed.
4 Change the settings on each tab as necessary.
The Trigger Condition tab and Options tab only appear in Advanced mode.
