IDEC MICRO/I HG1P-ST32 Series User Manual

WindO/I-NV4 User’s Manual 6-5
4 Drawings and Parts Overlapping
6
Drawings and Parts
This section describes when drawing and parts overlap.
4.1 Overview
Place the drawings and parts on the top layer to have precedence when these objects overlap on base screens and
popup screens.
Configure the Properties dialog box of the drawings or parts if they need to be placed on the top layer. For details,
refer to the settings for the drawings or part.
4 Drawings and Parts Overlapping
HG3G HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T HG4G HG1G HG1P
Base Screen or Popup Screen
Display for Base Screen or Popup Screen
130
100
120
130
100
120
Top Layer
