3 Picture Display
10-56 WindO/I-NV4 User’s Manual
3.1 How the Picture Display is Used
The Picture Display displays pictures. It can change, move, or scale the displayed picture according to value of device
address.
• Switch and display pictures by value of device address
3 Picture Display
HG3G HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T HG4G HG1G HG1P
External device
MICRO/I
D0
bit15 bit0
bit3
D0= 0100
bit0
bit3
D0= 0001
bit0
bit3
D0= 0010
bit0
bit3
D0= 0100
bit0
bit3
Pic0Pic1Pic2
