5 Message Display
10-98 WindO/I-NV4 User’s Manual
5.2 Message Display Configuration Procedure
This section describes the configuration procedure for Message Displays.
1 On the Home tab, in the Parts group, click Data Displays, and then click Message Display.
2 Click a point on the edit screen where you wish to place the Message Display.
3 Double-click the dropped Message Display and a Properties dialog box will be displayed.
4 Change the settings on each tab as necessary.
The Trigger Condition tab and Options tab only appear in Advanced mode.
To Next Page
