3 Picture Display
10-76 WindO/I-NV4 User’s Manual
3.4 Picture Display Usage Examples
● Rotating and Displaying a Picture
This example shows rotating and displaying a picture by the values of device addresses.
1 On the Home tab, in the Parts group, click Data Displays, and then click Picture Display.
2 Click a point on the edit screen where you wish to place the Picture Display.
3 Double-click the dropped Picture Display and a Properties dialog box will be displayed.
4 Click the View tab.
