4 Using the Data
14-34 WindO/I-NV4 User’s Manual
4.1 Display the Data in the Line Chart
You can display the sampled data in the Line Chart.
1 On the Home tab, in the Parts group, click Charts, and then click Line Chart.
2 Click a point on the edit screen where you wish to place the Line Chart.
3 Double-click the dropped Line Chart and a Properties dialog box will be displayed.
4 On the General tab, select Chart Type as Log Trend (Normal) or Log Trend (Pen Recorder).
4 Using the Data
HG3G HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T HG4G HG1G HG1P
