1 Overview
13-4 WindO/I-NV4 User’s Manual
1.3 Sampling Data
Data is sampled each time the alarm occurs, is recovered from, or confirmed.
Example: When the message for channel number 1-1 is “Voltage drop” and the message for channel number 1-2 is
“Temperature abnormal”
1
Channel No. 1-1: Alarm occurred
Ch.No.
Message Occurrence Time Recovery Time Confirmation Time
(12:50:00) 1-1 Voltage drop 12/01/2011 12:50:00 ‒‒
Channel No. 1-2: No alarm
2
Channel No. 1-1: Alarm
Ch.No.
Message Occurrence Time Recovery Time Confirmation Time
(12:50:00) 1-1 Voltage drop 12/01/2011 12:50:00 ‒‒
Channel No. 1-2: Alarm occurred
1-2
Tem pera ture
abnormal
12/01/2011 12:50:10
‒‒
(12:50:10)
3
Channel No. 1-1: Recovered from alarm
Ch.No.
Message Occurrence Time Recovery Time Confirmation Time
(12:50:20) 1-1 Voltage drop 12/01/2011 12:50:00 12/01 12:50:20 ‒
Channel No. 1-2: Alarm
1-2
Tem pera ture
abnormal
12/01/2011 12:50:10
‒‒
(12:50:10)
4
Channel No. 1-1: CHECK pressed
Ch.No.
Message Occurrence Time Recovery Time Confirmation Time
(12:50:30) 1-1 Voltage drop 12/01/2011 12:50:00 12/01 12:50:20 12/01 12:50:30
Channel No. 1-2: Alarm
1-2
Tem pera ture
abnormal
12/01/2011 12:50:10
‒‒
(12:50:10)
5
Channel No. 1-1: Alarm occurred
Ch.No.
Message Occurrence Time Recovery Time Confirmation Time
(12:51:00) 1-1 Voltage drop 12/01/2011 12:50:00 12/01 12:50:20 12/01 12:50:30
Channel No. 1-2: Alarm
1-2
Tem pera ture
abnormal
12/01/2011 12:50:10
‒‒
(12:50:10)
1-1 Voltage drop
12/01/2011 12:51:00 ‒‒
6
Channel No. 1-1: Alarm
Ch.No.
Message Occurrence Time Recovery Time Confirmation Time
(12:51:00) 1-1 Voltage drop 12/01/2011 12:50:00 12/01 12:50:20 12/01 12:50:30
Channel No. 1-2: CHECK pressed
1-2
Tem pera ture
abnormal
12/01/2011 12:50:10
‒ 12/01 12:52:10
(12:52:10)
1-1 Voltage drop
12/01/2011 12:51:00 ‒‒
7
Channel No. 1-1: Alarm
Ch.No.
Message Occurrence Time Recovery Time Confirmation Time
(12:51:00) 1-1 Voltage drop 12/01/2011 12:50:00 12/01 12:50:20 12/01 12:50:30
Channel No. 1-2: Recovered from alarm
1-2
Tem pera ture
abnormal
12/01/2011 12:50:10 12/01 12:53:00 12/01 12:52:10
(12:52:10)
1-1 Voltage drop
12/01/2011 12:51:00 ‒‒
