WindO/I-NV4 User’s Manual 8-101
5 Key Button
8
Buttons
5.6 Key Button Usage Examples
● Recording Images and Sound
This section describes how to record using the Rec. and Stop key buttons.
Configuration Procedure
1 On the Home tab, in the Parts group, click Buttons, and then click Key Button.
2 Click a point on the edit screen where you wish to place the Key Button.
3 Double-click the dropped Key Button and a Properties dialog box will be displayed.
4 On the General tab, under Key Type, click Browse.
Key Browser is displayed.
*1 Recording sound function is for HG4G/3G only
*1
HG3G HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T HG4G HG1G HG1P
