6 Multi-Button
8-110 WindO/I-NV4 User’s Manual
6.2 Multi-Button Configuration Procedure
This section describes the configuration procedure for Multi-Buttons.
1 On the Home tab, in the Parts group, click Buttons, and then click Multi-Button.
2 Click a point on the edit screen where you wish to place the Multi-Button.
3 Double-click the dropped Multi-Button and a Properties dialog box will be displayed.
4 Change the settings on each tab as necessary.
The Trigger Condition tab and Options tab only appear in Advanced mode.
